Butterfly Damper valve DN 200
For fumes and air at high temperatures type
AMM780
Max. working temperature 1000°C (for
discontinuous service)
Max. working pressure 3 bar
WAFER connections for flanges EN 1092-1
PN 6
Entirely in AISI 310
Ceramic Fiber packing on Shaft
Cooling fin system on the support
Shaft with thermal cut
Outside bushing supports
Metal to Metal seat
Max. leakage class: I as per ANSI B16.104
(Relative Tightness)
Face to face 140 mm
Complete with Handwheel
For fumes and air at high temperatures type
AMM780
Max. working temperature 1000°C (for
discontinuous service)
Max. working pressure 3 bar
WAFER connections for flanges EN 1092-1
PN 6
Entirely in AISI 310
Ceramic Fiber packing on Shaft
Cooling fin system on the support
Shaft with thermal cut
Outside bushing supports
Metal to Metal seat
Max. leakage class: I as per ANSI B16.104
(Relative Tightness)
Face to face 140 mm
Complete with Handwheel
