| Poids brut (kg) | 0 |
| Eclass | 27220000 |
| UNSPSC Code | 31251500 |
SITRANS FVA 250
Version: Type: CF-S (standard)
Fitting: Stainless steel 1.4404/316L, Flange: Stainless steel 1.4404/316L
Float: Stainless steel 1.4404/316L
Process connection size
DN 25 PN 40 B1 DIN EN 1092-1
Measuring range Liquid/Gas: L: 160 - 1600 L/h / G: 4 - 46 m3/h
Display unit / Process temperature: Standard (Aluminium) 150/200°C
Heating/cooling sheath: Without (standard)
Display: With local display, HART , 4-20 mA
Calibration: Standard calibration (without calibration certificate)
Y01:
Medium: Kersosin
Density: 0,785 kg/l
Viscosity: 4 cSt
Temperature: 25°C
Pressure: 3,5 bar
Measurement Range Qv: 3 - 30 l/min.
Version: Type: CF-S (standard)
Fitting: Stainless steel 1.4404/316L, Flange: Stainless steel 1.4404/316L
Float: Stainless steel 1.4404/316L
Process connection size
DN 25 PN 40 B1 DIN EN 1092-1
Measuring range Liquid/Gas: L: 160 - 1600 L/h / G: 4 - 46 m3/h
Display unit / Process temperature: Standard (Aluminium) 150/200°C
Heating/cooling sheath: Without (standard)
Display: With local display, HART , 4-20 mA
Calibration: Standard calibration (without calibration certificate)
Y01:
Medium: Kersosin
Density: 0,785 kg/l
Viscosity: 4 cSt
Temperature: 25°C
Pressure: 3,5 bar
Measurement Range Qv: 3 - 30 l/min.
