Bourdon tube pressure gauges,model 111
Model: 111.11
Specifications according to data sheet
Model: 111.11 welding
Nominal size: 050 mm
Unit of outer Scale: bar
Measuring range: gauge pressure range
Scale range: 0...6 bar
2nd Scale or Special Scale: 1st scale 20 l/min
2nd scale bar
Process connection: G 1/4 B
Connector location: lower mount
Case: black steel with pressure vent
Window: polycarbonate
Restrictor: brass, D 0.3
Accuracy class: class 2.5
Pointer: plastic, black
Packaging: standard packing
Dial: plastic, white, with stop-pin
Specifications according to data sheet: PM 01.03
Dial description:
Pressure Gauge Standard: International (standard Europe)
color for 1.scale (outside): black
color for 2.scale (inside): red RAL 3020
dial background: White
mark on dial: mark standard en 562 / iso5171
mark-color: red
individual text for dial: *20 l/min = 5,8 bar*
Manufacturer logo: *WIKA*
stop pin on dial: at zero
norm-mark on dial: *ISO 5171*
accuracy class on dial: *Cl.2.5*
