Spool valve - 5/3 CC - G1/4" - Muscular with lever - 3 held positions - With gaskets

Name: Spool valve - 5/3 CC - G1/4" - Muscular with lever - 3 held positions - With gaskets
Brand: Metal Work
SKU: 7020000500
Price: 85.25 EUR
Availability: InStock

Reference : 7020000500

Catalog Price :

€85.25

Tax excluded 21.00 %

Stock Luxembourg (Troisvierges)	-
Stock Belgium (Barchon)	-
Stock Belgium (Chaineux)	Quantity and short lead time to be confirmed on request
Manufacturer stock	Quantity and short lead time to be confirmed on request

Function	5/3 Center closed
Operated	Muscular with lever
Return	3 maintained positions
Body material	Aluminum
Joints	With
Diameter of connection	1/4"
Max flow (Normolitres)	1100 Nl/min
Operating pressure	2,5 to 10 bar
Control pressure	2,5 to 10 bar
Fluid working Temp	(-)10°C to (+)60°C
Compatibility - fluids	Air or neutral gas, filtered, lubricated or not
Customs duty number	8481-8099
Gross weight (kg)	0,301739
Eclass	27290000
Country of origin	IT
UNSPSC Code	27131700
