| Supplier series | APR 200 |
| Operated | Air operated |
| Body material | Technopolymere |
| Seal material | NBR |
| Diameter of connection | 3/8" |
| Max flow (Normolitres) | 2000 Nl/min |
| Max input pressure at 23°C | 13 bar |
| Set pressure | 6 bar |
| ?P load loss | 0,5 bar |
| Fluid working Temp | (-)10°C to (+)50°C |
| Compatibility - fluids | Air or neutral gas |
| Gross weight (kg) | 0 |
| Eclass | 27290000 |
| UNSPSC Code | 27131700 |
Slow start - quick exhaust valve with air pilot METAL WORK Serie APR200
- Pneumatic command
- Body technopolymer
- Seal NBR
- Fitting diameter G3/8"
- Pilot orifice diameter : G 1/8"
- Maximum inlet pressuer at 23 °C : 13 bar
- Service fluide temperature : -10 to 50 °C
- Appropriate silencer reference not supplied : PASE.YB.001.1414
- Pneumatic command
- Body technopolymer
- Seal NBR
- Fitting diameter G3/8"
- Pilot orifice diameter : G 1/8"
- Maximum inlet pressuer at 23 °C : 13 bar
- Service fluide temperature : -10 to 50 °C
- Appropriate silencer reference not supplied : PASE.YB.001.1414
Associated products
PASE.YB.001.1414
Silencer - Brass - 1/4" M - 12 bar
