Reference : CHFX.007.125
Brand reference : FIG. 261 DN125
Catalog Price :
€1,372.11
Tax excluded 21.00 %
| Body material | Cast steel |
| Sealing | Graphite/Metal |
| Type of connection | With flanges |
| Diameter of connection | DN125 |
| GN | 40 |
| PN | 40 |
| Fluid working Temp | (-)10°C to (+)400°C |
| Operation | Horizontal or vertical mounting |
| Specifications | Spring check |
| Compatibility - fluids | For water, hot water, steam and compressed air |
| Customs duty number | 8481-8073 |
| Gross weight (kg) | 125 |
| Eclass | 37010000 |
| Country of origin | CH |
| UNSPSC Code | 40140000 |
F&M spring loaded check valve:
- Steel body
- Graphite/metal seal
- Flanged connection in DN125
- PN40
- GN40
- Operation: horizontal installation only
- Without control
- Operating temperature of the fluid : (-)10°C to (+)400°C
- Steel body
- Graphite/metal seal
- Flanged connection in DN125
- PN40
- GN40
- Operation: horizontal installation only
- Without control
- Operating temperature of the fluid : (-)10°C to (+)400°C
