Filter Regulator Lubricator ASCO Serie 651 - G1/4" - 25 µm - 0,5 to 10 bar - Automatic drain

Name: Filter Regulator Lubricator ASCO Serie 651 - G1/4" - 25 µm - 0,5 to 10 bar - Automatic drain
Brand: Asco
SKU: A651A0000000405
Price: 225.52 EUR
Availability: InStock

Reference : A651A0000000405

Catalog Price :

€225.52

Tax excluded 21.00 %

Stock Luxembourg (Troisvierges)	2
Stock Belgium (Barchon)	3
Stock Belgium (Chaineux)	Quantity and short lead time to be confirmed on request
Manufacturer stock	Quantity and short lead time to be confirmed on request

Supplier series	651
Body material	Aluminum
Piston seal material	NBR
Tank material	Polycarbonate
Filtration	25 µm
Total lubricant tank capacity	42 cm³
Diameter of connection	1/4"
Max flow at upstream pressure	10 bar
Max flow (ANR)	2360 l/min
Regulation pressure	0,5 to 10 bar
Max input pressure at 23°C	10 bar
Set pressure	6,3 bar
?P load loss	1 bar
Fluid working Temp	(+)5°C to (+)50°C
Compatibility - fluids	Air or neutral gas
Customs duty number	8481-1005
Gross weight (kg)	0,72
Eclass	27290000
Country of origin	PL
UNSPSC Code	27131700

Description
Documents

651 SERIES FRL ASSEMBLY, G1/4 PORT SIZE, POLYCARBONATE BOWL, AUTOMATIC DRAIN, INTEGRATED FLAT GAUGE, 0-10 BAR REGULATION ZONE, 25 MICRON FILTER ELEMENT (G651APJP2GA00HA + G651AL0P20A0000)
